4040 Mixer
The Penta 4040 is a rugged single-auger trailer mixer engineered for low loading height. Easily filled with a skid steer it can feed appoximately 65 cows per load. Built with durable components and the Penta Cyclone Auger, it delivers consistent, thorough mixing while withstanding demanding daily use.
Specifications
- CAPACITY
- 9″ Rubber Ext.
- 418 ft3
- 71.8 m3
- CAPACITY
- 16″ Rubber Ext.
- 466 ft3
- 13.2 m3
- WIDTH
- 105 in
- 267 cm
- LENGTH
- 233 in
- 592 cm
- HEIGHT
- Standard Tires
- 99 in
- 251 cm
- MIN HP
- 80 hp
- EMPTY WEIGHT
- 10,360 lbs
Additional Info
Capacity in a compact footprint
- Farm-Proven Durability — Designed for long hours and extreme field conditions.
- Patented Cyclone Auger — Accelerates forage circulation faster, and more consistent mixing.
- Heavy-Duty Construction — Rugged frame, tub, and augers designed for durability and optimal performance under pressure.
- Planetary Gear Drive — Planetary gearboxes deliver reliable power and cleaner operation.
- Efficient Unloading — Optional flip‑up or dual conveyors, driven by tough C188 chain and hydraulic motors.
Read Our 40 Series Brochure
