5540 Mixer
The Penta 5540 is a heavy-duty single-auger trailer mixer built for larger operations. It boasts up to 540 cu ft capacity, rugged construction, and the patented Cyclone Augers, which delivers fast, consistent mixing day in and day out.
Specifications
- CAPACITY
- 9″ Rubber Ext.
- 540 ft3
- 15.3 m3
- CAPACITY
- 16″ Rubber Ext.
- 604 ft3
- 17.1 m3
- WIDTH
- 90 in
- 229 cm
- LENGTH
- 316 in
- 803 cm
- HEIGHT
- Standard Tires
- 106 in
- 269 cm
- MIN HP
- 115 hp
- EMPTY WEIGHT
- 15,200 lbs
Additional Info
Built for higher capacity needs
- Farm-Proven Durability — Designed for long hours and extreme field conditions.
- Patented Cyclone Auger — Accelerates forage circulation with faster, more consistent mixing via drop-through design.
- Heavy-Duty Construction — Built with rugged steel tubing: ¾″ cold-pressed flighting and thick structural frames.
- Planetary Gear Drive — Corner planetary gearboxes (3‑year warranty) deliver reliable power and cleaner operation.
- Efficient Unloading — Optional flip‑up or dual conveyors, driven by tough C188 chain and hydraulic motors.
Read Our 40 Series Brochure
